Within one schematic session, both analog circuit simulation leveraging the power and flexibility of VHDL-AMS, (an IEEE standard, along with a SPICE-based simulation engine), and topology exploration with the HyperLynx tool can be performed. The PADS AMS Design Suite is said to empower engineers to design and simulate analog/mixed-signal (AMS) and digital in one environment.
Violations, such as this net-crossing violation, are identified so they can be rectified early in the design flow when it is easiest and least expensive. The PADS HyperLynx DRC tool identifies potential PCB design problems using design rule checking. A special benefit for PADS customers: Circuit designs created in PADS AMS Cloud can be transferred to the PADS AMS Design Suite desktop environment, eliminating the need to manually recreate circuits to perform advanced analysis and drive the PCB design flow.
Users from all levels of expertise can create and share analog, mixed-signal, and mixed-technology designs in an online, collaborative environment where designs and models can be published or downloaded. To address this need, the new PADS AMS Cloud – which is a cloud-based circuit exploration/simulation environment and user community – is available FREE for all PADS users. Mentor’s rationale for the new release is that the vast majority of today’s electronic products contain analog content which must be designed and validated in the context of the overall system, making analog/mixed signal simulation critical for product creation. The new PADS Product Creations Platform includes an analog/mixed signal cloud-based circuit exploration and simulation environment, and user community, free to all PADS customers. Combined with the recently announced PADS HyperLynx DC Drop and PADS FloTHERM XT products for power integrity and thermal analysis, the extended PADS Product Creation Platform is said to give better access to technologies formerly out of reach for the mainstream PCB market. The additions consist of a new PADS AMS Design Suite, PADS AMS Cloud, PADS HyperLynx DRC, and PADS HyperLynx DDR modules.
Platform designed to address engineering challenges associated with mixed-signal design, DDR implementation, and electrically-correct design signoff. has made additions to its PADS PCB Product Creation
